Thermal Printer Xprinter XP-76IIH
Xprinter XP-76IIH 9-pin impact receipt printer, 4.5 lines/s, USB, LAN and parallel interfaces, original plus two copies, partial auto cutter
- Brand
- Xprinter
- Category
- Thermal Receipt Printer
- Model
- XP-76IIH
Available Alternatives to XP-76IIH
Printer Specifications
- تقنية الطباعة
- 9-Pin Serial Impact Dot-Matrix Printing
Media Handling
- Media Width
- 75.5 ± 0.5 mm
- Maximum Paper Roll Diameter
- 80 mm
- Black Mark Detection
- Yes
- Paper End Sensor
- Yes
- Print Width
- 63.5 mm
- Printer Emulation
- ESC/POS Compatible
- سرعة الطباعة
- 4.5 lines/s mm/s
Printing
- Column Capacity
- 400 dots/line
- Line Spacing
- 4.23 mm
- Adjustable Line Spacing
- Yes
- Column Number
- Font A: 32 columns; Font B: 42 columns; Simplified/Traditional Chinese: 16 columns
- Copy Capability
- One original and two copies
- Bi-directional Printing
- Yes
Fonts
- Font A Size
- 1.6 × 3.1 mm (9 × 9 dots)
- Font B Size
- 1.2 × 3.1 mm (7 × 9 dots)
- Chinese Font Size
- 2.7 × 2.7 mm (16 × 16 dots)
- Character Set
- PC347 (Standard Europe), Katakana, PC850 (Multilingual), PC860 (Portuguese), PC863 (Canadian-French), PC865 (Nordic), West Europe, Greek, Hebrew, East Europe, Iran, WPC1252, PC866 (Cyrillic #2), PC852 (Latin 2), PC858, Iran II, Latvian, Arabic, PT151 (Windows-1251)
- Supported International Languages
- Simplified Chinese, Traditional Chinese and multiple international character sets
Power
- Power Adapter Input
- AC 110/220 V, 50–60 Hz
- Power Adapter Output
- DC 24 V, 2.5 A
- Printer Input
- DC 24 V, 2.5 A
- Cash Drawer Output
- DC 24 V, 1 A
Environment
- Operating Temperature
- 0–45 °C
- Operating Humidity
- 10–80 %
- Storage Temperature
- -10–60 °C
- Storage Humidity
- 10–90, non-condensing %
Reliability
- Auto Cutter
- Partial Auto Cutter
- Printhead Life
- 10 million lines km
Connectivity
- Interface
- Parallel / USB / USB + LAN
General
- Model
- XP-76IIH
Features
- Multi-copy Invoice Printing Support
- Yes
Quick comparison with available alternatives
| Attribute | Reference model | Thermal Printer Xprinter XP-... | Thermal Printer Xprinter Xp... |
|---|---|---|---|
| سرعة الطباعة | 4.5 lines/s | 230/260/300 | 230 |
| تقنية الطباعة | 9-Pin Serial Impact Dot-Matrix Printing | Direct Thermal | Direct Thermal |
| Interface | Parallel / USB / USB + LAN | USB | USB + LAN |
| Media Width | 75.5 ± 0.5 | 79.5±0.5 | 79.5±0.5 |
| Operating Temperature | 0–45 | 0–45 | 0–45 |
| Storage Temperature | -10–60 | -10–60 | -10–60 |
| Operating Humidity | 10–80 | 10–80 | 10–80 |
| Storage Humidity | 10–90, non-condensing | 10–90 | 10–90 |
Compare with available products
Frequently asked questions about Xprinter XP-76IIH receipt printer
What is the main advantage of the Xprinter XP-76IIH?
Its main advantage is the ability to print one original and two copies through a 9-pin impact dot-matrix mechanism. This is useful for businesses that need several copies of the same invoice or work document in one print cycle.
What businesses can use the Xprinter XP-76IIH?
It is suitable for restaurants, warehouses, service centers, and POS operations that require multi-copy invoices or operational documents. Compatible software can use it to print text-based receipts and work orders on 75.5 mm media.
What print speed and printhead life does the XP-76IIH offer?
The printer operates at up to 4.5 lines per second, and the printhead is rated for 10 million lines. This makes it suitable for regular text-based and multi-copy document printing.
What connectivity and operating features does the XP-76IIH provide?
It is available with parallel, USB, or USB plus LAN connectivity and supports ESC/POS and bi-directional printing. It also includes a partial automatic cutter and paper-end sensor, depending on the supplied configuration.
Is the Xprinter XP-76IIH suitable for businesses in Syria?
It can suit restaurants, warehouses, and service centers in Syria, including Damascus, Aleppo, and Homs, when one original and two copies are required. Interface, software, and paper compatibility should be confirmed before purchase.
Is Xprinter XP-76IIH available to buy?
No — this is a reference page for the model, and it is not currently listed for sale at EvoLink. Specs are shown for research and comparison with available alternatives.
Where can I find a similar alternative to Xprinter XP-76IIH?
You can review currently available alternatives to XP-76IIH: Thermal Printer Xprinter XP-Q838L - 80mm · Thermal Printer Xprinter Xp Q851 L - 80MM.
