Thermal Printer Xprinter XP-H230L
Xprinter XP-H230L thermal receipt printer, 230 mm/s, 58 and 80 mm paper, USB, Ethernet, Bluetooth or Wi-Fi, QR Code, PDF417, sound and LED alert
- Brand
- Xprinter
- Category
- Thermal Receipt Printer
- Model
- XP-H230L
Currently Available Options
Printer Specifications
- تقنية الطباعة
- Direct thermal
Media Handling
- Media Width
- 79.5±0.5 mm
- Maximum Paper Roll Diameter
- 80 mm
- Supported Paper Roll Widths
- 58, 80 mm
- Print Width
- 72 mm
- سرعة الطباعة
- 230 mm/s
- Input Buffer
- 64 KB
Printing
- Column Capacity
- 576 dots/line or 512 dots/line dots/line
- Line Spacing
- 3.75 mm
- Adjustable Line Spacing
- Yes
- Column Number
- Font A: 42 or 48 columns; Font B: 56 or 64 columns; Simplified/Traditional Chinese: 21 or 24 columns
Memory
- NV Flash Memory
- 256 KB
Fonts
- Font A Size
- 1.5×3.0 mm (12×24 dots)
- Font B Size
- 1.1×2.1 mm (9×17 dots)
- Chinese Font Size
- 3.0×3.0 mm (24×24 dots)
- Character Set
- PC347, Katakana, PC850, PC860, PC863, PC865, West Europe, Greek, Hebrew, East Europe, Iran, WPC1252, PC866, PC852, PC858, Latvian, Arabic, PT151 (1251)
Barcode Support
- Supported 1D Barcodes
- UPC-A, UPC-E, JAN13 (EAN13), JAN8 (EAN8), CODE39, ITF, CODABAR, CODE93, CODE128
- Supported 2D Barcodes
- QR Code, PDF417
Power
- Power Adapter Input
- AC 100–240V, 50–60Hz
- Power Adapter Output
- DC 24V/2.5A
- Cash Drawer Output
- DC 24V/1A
Physical
- Dimensions
- 193×145×132 mm (D×W×H) mm
- Weight
- 1.76 kg
- Wall Mount Support
- Yes
- Printer Placement Orientation
- Horizontal, vertical or wall-mounted
Environment
- Operating Temperature
- 0–45 °C
- Operating Humidity
- 10–80 %
- Storage Temperature
- -10–60 °C
- Storage Humidity
- 10–90, non-condensing %
Reliability
- Cutter Life
- 1500000 cuts
- Printhead Life
- 150 km
Connectivity
- Interface
- USB or Ethernet or USB + Bluetooth or USB + Wi-Fi
Features
- Order Coming Alert
- Yes
- QR Code Printing
- Yes
- LED Sound and Light Alarm
- Yes
General
- Model
- XP-H230L
Quick comparison with available alternatives
| Attribute | Reference model | Thermal Printer Xprinter XP-... | Thermal Printer Xprinter Q80... |
|---|---|---|---|
| سرعة الطباعة | 230 | 120 | 230 |
| تقنية الطباعة | Direct thermal | Direct Thermal | Direct Thermal |
| Interface | USB or Ethernet or USB + Bluetooth or USB + Wi-Fi | Parallel, Serial, USB, LAN | USB |
| Media Width | 79.5±0.5 | 57.5±0.5 | 79.5±0.5 |
| Operating Temperature | 0–45 | 0–45 | 0–45 |
| Storage Temperature | -10–60 | -10–60 | -10–60 |
| Operating Humidity | 10–80 | 10–80 | 10–80 |
| Storage Humidity | 10–90, non-condensing | 10–90 | 10–90 |
Compare with available products
Frequently asked questions about Xprinter XP-H230L receipt printer
What is the main advantage of the Xprinter XP-H230L?
Its main advantage is flexible installation and connectivity. It can be positioned horizontally, vertically, or wall-mounted and is available with USB, Ethernet, USB plus Bluetooth, or USB plus Wi-Fi. It also provides sound and LED incoming-order alerts.
What businesses can use the Xprinter XP-H230L?
It is suitable for restaurants, cafés, kitchens, retail stores, pharmacies, and service counters that need receipt or order printing. Sound and light alerts are useful in busy environments, while QR Code, PDF417, and common one-dimensional barcodes are supported.
What print speed and paper sizes does the XP-H230L support?
The printer reaches up to 230 mm/s and supports 58 mm or 80 mm rolls with a maximum diameter of 80 mm. Its 72 mm printable width provides flexibility for compact receipts or wider layouts containing additional transaction details.
Which Xprinter XP-H230L connection version should I choose?
Available versions include USB, Ethernet, USB plus Bluetooth, and USB plus Wi-Fi. USB suits direct wired setups, while Ethernet and Wi-Fi are useful for network installations. Buyers should confirm compatibility with their POS hardware and software.
Is the Xprinter XP-H230L suitable for businesses in Syria?
Yes, it can suit restaurants and shops in Syria, including Damascus and Aleppo, that need 58 mm or 80 mm receipt printing with clear order alerts. Buyers should select the required connection version and confirm POS software compatibility before ordering.
Is Xprinter XP-H230L available to buy?
No — this is a reference page for the model, and it is not currently listed for sale at EvoLink. Specs are shown for research and comparison with available alternatives.
Where can I find a similar alternative to Xprinter XP-H230L?
You can review currently available alternatives to XP-H230L: Thermal Printer Xprinter XP-T58H · Thermal Printer Xprinter Q80B - 80mm.
Or browse Xprinter products in Thermal Receipt Printer.
For help choosing, contact us on WhatsApp.
